Quick Details

  • Place of Origin: Henan, China (Mainland)
  • Brand Name: Chongpeng
  • Model Number: JK
  • Power Source: Electric
  • Application: Cranes
  • Capacity: 10KN
  • rated speed: 22 m/min
  • Electromotor type: Y112M-4
  • Weight: 300kg
  • Color: design as your requirement
  • rope capacity: 100m
  • Electromotor power: 4KN
  • Warranty: 1 year
  • rope diameter: 9.3mm
  • orm dimension: 620x701x417mm
  • voltage: 380v

Packaging & Delivery

Packaging Details Electricals and other parts are packed by high quality plywood crates, or as your special requirement.
Delivery Time 3 days after payment



High speed small wire rope winch

Product Description



JK electric hoisting and lowering winch is mainly used for hoisting heavy cargos in construction site, factory, mine, port, JK winch is suitable for free fall punching & piling for bridge, dock, construction works and so on.



JK electric hoisting and lowering winch we sell is in compliance with the national standard. The design of hoisting and lowering winch is reasonable, The materials are of good quality, The structure is advanced. The appearance of hoisting and lowering winch is beautiful and the size is compact, the weight is light, the hand pull force is small and parts have high strength, big tenacity, and all these make hoisting and lowering winch safe and durable. And mine winches are popular at home and abroad.





The standard capacity of electric winch: 1t, 1.6t, 2t, 3.2t, 5t, 6t, 8t, 10t, 12.5t, 13.5t, 16t, 20t, 25t, 32t, 50t, 65t.

The Max. rope length reach to 1500m.



Technical parameters

ModelRated load
(KN)
Rated Speed
(m/min)
Rope Capacity(m)Rope Dia(mm)Motor

Power

(kw)

Dimension(mm)Weight(KG)
JK0.5522907.7Y100L-43620*701*417200
JK110221009.3Y112M-44620*701*417300
JK1.6162415012.5Y132S-45.5945*996*570500
JK2202415013Y132M-47.5945*996*570550
JK3.2322529015.5YZR180L-6151325*1335*8401011
JK3.2B323025015.5YZR200L-6221900*1738*9851500
JK5503030021.5YZR225M-6301900*1620*9852050
JK5B502521021.5YZR225M-8222250*2500*13002264
JK8802516026YZR280S-8451533*1985*10453000
JK101003030030YZR315S-8552250*2500*13005100















Packaging







Our company

Anlian Xinxiang Crane Construction Machinery Co., Ltd., the main business: electric hoist, hoist, crane motors, conical motors, vibration motors, concrete vibrators and hoist accessories, which widely used in various fields of materials handling, such as machinery manufacturing, iron and steel metallurgy, mine mining, water conservancy and hydropower, road and rail, port logistics, shipbuilding and so on. Founded in 1993, after years of development, as a whole of development, design, manufacture, sale, installation and service, it has become the equipment manufacturing enterprises. Currently has a registered capital of 10 million yuan, more than 200 employees, 20 engineers and technicians, covers an area of 24,000 square meters, with all kinds of production equipment 90 (sets).



Certifications


Customers Visiting



After-Sales Service

1. One year guarantee for main body.
2. We provide free maintenances for spare parts, but the new components replaced should be paid.
3. Delivery with English version user manual, parts manual, test certificates, class certificate and all other related documents.
4. Technique support: Exclusive engineer support at any time .





FAQ

Q1: What is our factory product range?



A:We are specialize in crane, electric motors, wire rope hoists, electric winches and concrete vibrators, etc. for many years.





Q2:How about sample policy?



A:Welcome sample order. Please inform your detailed sample requirement, such as the quantity, the capacity, the chain, the lift and so on. If we have the sample in stock , the ship will be quicker. If we don’t have stock, please understand to wait for the produce. Express fee is charged by the shipping company. The sample fee and express fee usually paid by client, for special policy need to apply by client and approved by our leaders.





Q3: How to order?



A: Please send us your purchase order by Email or Fax, or you can ask us to send you Performa Invoice for your order. We need to know the following information for your order:
    1)About product: Quantity, Specification (type, capacity, voltage, size, material, color and packing requirement),
    2) Delivery time required.
    3) Shipping information: Company name, Address, Phone number, Destination seaport/airport.
    4) Forwarder's contact details if there is any in China.





Q4: What advantages we have?



 A: 1) One to one service guarantees the best purchasing experience for you.

      2) Strong production capacity and professional workmen guarantee you the short delivery.

      3) Strict delivery inspection guarantees the high quality products.



Any inqiury, pls do not hesitate to contact us!
